主要性能：
主要材料：由AISI 410或AISI 420防腐钢制成，The flexing elements由AISI 420防腐钢制成
扭转弹簧速度：一般在＋/-10％之内或是低于列表数值
|
Bearing Series |
LOAD CAPACITY |
RADIAL STIFFNESS |
||||
|
A Series |
Lc |
Lt |
Axial |
Lc |
Lt |
Axial Stiffness |
|
10 |
0.95 |
3.80 |
6.08 |
0.00050 |
0.00100 |
0.00050 |
|
20 |
8.90 |
12.70 |
12.70 |
0.00025 |
0.00050 |
0.00030 |
|
30 |
25.30 |
25.30 |
25.30 |
0.00017 |
0.00025 |
0.00030 |
|
B Series |
||||||
|
10 |
1.40 |
5.60 |
8.96 |
0.00033 |
0.00050 |
0.00030 |
|
20 |
13.70 |
19.60 |
19.60 |
0.00017 |
0.00025 |
0.00020 |
|
30 |
39.30 |
39.30 |
39.30 |
0.00013 |
0.00017 |
0.00013 |
|
C Series |
||||||
|
10 |
2.00 |
7.80 |
12.48 |
0.00025 |
0.00033 |
0.00025 |
|
20 |
19.50 |
27.90 |
27.90 |
0.00014 |
0.00017 |
0.00013 |
|
30 |
55.80 |
55.80 |
55.80 |
0.00009 |
0.00011 |
0.00008 |
|
D Series |
||||||
|
10 |
3.60 |
14.20 |
22.72 |
0.00022 |
0.00020 |
0.00014 |
|
20 |
35.00 |
50.00 |
50.00 |
0.00010 |
0.00011 |
0.00008 |
|
30 |
100.00 |
100.00 |
100.00 |
0.00006 |
0.00008 |
0.00005 |
|
E Series |
||||||
|
10 |
5.70 |
22.80 |
36.48 |
0.00014 |
0.00014 |
0.00010 |
|
20 |
55.00 |
78.60 |
78.60 |
0.00008 |
0.00008 |
0.00006 |
|
30 |
157.10 |
157.10 |
157.10 |
0.00005 |
0.00006 |
0.00004 |
|
F Series |
||||||
|
10 |
8.40 |
33.60 |
53.76 |
0.00013 |
0.00008 |
0.00010 |
|
20 |
79.10 |
113.00 |
113.00 |
0.00007 |
0.00006 |
0.00006 |
|
30 |
226.00 |
226.00 |
226.00 |
0.00005 |
0.00003 |
0.00004 |
|
G Series |
||||||
|
10 |
14.40 |
57.40 |
91.84 |
0.00010 |
0.00006 |
0.00008 |
|
20 |
140.00 |
200.00 |
200.00 |
0.00005 |
0.00003 |
0.00005 |
|
30 |
400.00 |
400.00 |
400.00 |
0.00003 |
0.00002 |
0.00003 |
|
H Series |
||||||
|
10 |
23.00 |
92.00 |
147.20 |
0.00008 |
0.00005 |
0.00006 |
|
20 |
221.10 |
315.80 |
315.80 |
0.00004 |
0.00002 |
0.00003 |
|
30 |
631.50 |
631.50 |
631.50 |
0.00003 |
0.00002 |
0.00002 |
|
I Series |
||||||
|
10 |
32.40 |
129.40 |
207.40 |
0.00006 |
0.00004 |
0.00005 |
|
20 |
317.20 |
453.10 |
453.10 |
0.00003 |
0.00002 |
0.00003 |
|
30 |
906.10 |
906.10 |
906.10 |
0.00002 |
0.00001 |
0.00002 |
|
J Series |
||||||
|
10 |
59.20 |
236.60 |
378.88 |
0.00005 |
0.00003 |
0.00004 |
|
20 |
566.30 |
809.00 |
809.00 |
0.00002 |
0.00001 |
0.00002 |
|
30 |
1616.00 |
1616.00 |
1616.00 |
0.00001 |
0.00001 |
0.00001 |
单轴承系列：
10系列A-10 B-10 C-10 D-10 E-10 F-10 G-10 H-10 I-10 J-10
20系列A-20 B-20 C-20 D-20 E-20 F-20 G-20 H-20 I-20 J-20
30系列A-30 B-30 C-30 D-30 E-20 F-30 G-30 H-30 I-30 J-30
双轴承系列：
10系列AD-10 BD-10 CD-10 DD-10 ED-10 FD-10 GD-10 HD-10 ID-10 JD-10
20系列AD-20 BD-20 CD-20 DD-20 ED-20 FD-20 GD-20 HD-20 ID-20 JD-20
30系列AD-30 BD-30 CD-30 DD-30 ED-30 FD-30 GD-30 HD-30 ID-30 JD-30
订货须知：用户可提供表格中的代号，或扭簧的尺寸数据，表格中的单位是英寸，换算尺寸
1英寸=25.4mm
